Midea R410A 50Hz T1 Compressor Condensing Unit
8
Model
MCCU-07CN1
MCCU-10CN1
Power supply
\
220-240V~, 1Ph, 50Hz
380-415V~, 3Ph, 50Hz
Ambient temperature range
°C
17~46
17~46
Cooling
Capacity
kW
7.1
10.5
Max. input
kW
3.50
5.30
Max. current
A
18.0
10
Noise level
dB(A)
72.6
58
Compressor
Type / Quantity
\
Rotary / 1
Scroll / 1
Model
\
PA290G2CS-4MU1
C-SBN303H8D
Brand
\
GMCC
Sanyo
Capacity
W
7,260
9,800
Input
W
2,430
3,650
Capacitor
\
50µF/450V
/
Rated current (RLA)
A
11.65
6.58
Oil charge
\
850 (Ester oil VG74)
1,700 (FV68S)
Refrigerant
Type / Charged
\
R410A / 1,350g
R410A / 2,500g
Fan
Type / Quantity
\
Axial fan / 1
Axial fan / 1
Motor model
\
YDK53-6C
YDK190-6D(B)
Fan dimension
mm
Φ460
Φ560
Drive type
\
Direct
Direct
Capacitor
\
3µF/450V
10µF/450V
Motor input
W
136
290
Motor speed
rpm
800
830
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Φ7
Φ7
No. of rows
\
2
1.6
Fin space
mm
1.5
1.5
Length × Height
mm
766×630
898×882
Number of circuits
\
4
7
Refrigerant
pipe
Liquid side / Gas side
mm
Φ9.52/Φ12.7
Φ9.52/Φ19
Max. pipe length
m
20
30
Max. difference in level
m
10
20
Connection
wire
Power wire
\
2×6.0mm
2
+1×4.0mm
2
(Ground)
4×4.0mm
2
+1×2.5mm
2
(Ground)
Signal wire
\
1×1.0mm
2
1×1.0mm
2
Dimension (W×H×D)
mm
916×702×360
1,077×967×396
Packing (W×H×D)
mm
965×755×420
1,120×1,100×435
Net / Gross weight
kg
48.5/52
85.8/95.6
Notes:
Nominal cooling capacities are based on the following conditions:
Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.
