Midea R410A 50Hz T1 Compressor Condensing Unit
9
Model
MCCU-12CN1
MCCU-16CN1
Power supply
\
380-415V~, 3Ph, 50Hz
380-415V~, 3Ph, 50Hz
Ambient temperature range
°C
17~46
17~46
Cooling
Capacity
kW
14.0
16.0
Max. input
kW
6.10
8.50
Max. current
A
12
13
Noise level
dB(A)
58
59
Compressor
Type / Quantity
\
Scroll / 1
Scroll / 1
Model
\
C-SBN373H8D
C-SBN453H8D
Brand
\
Sanyo
Sanyo
Capacity
W
14,100
16,400
Input
W
4,750
5,750
Capacitor
\
/
/
Rated current (RLA)
A
8.22
9.77
Oil charge
\
1,700 (FV68S)
1,700 (FV68S)
Refrigerant
Type / Charged
\
R410A / 3,000g
R410A / 3,050g
Fan
Type / Quantity
\
Axial fan / 2
Axial fan / 2
Motor model
\
YDK65-6F(B)
YDK65-6F(B)
Fan dimension
mm
Φ455
Φ455
Drive type
\
Direct
Direct
Capacitor
\
4µF/450V
4µF/450V
Motor input
W
174
174
Motor speed
rpm
825
825
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Φ7
Φ7.94
No. of rows
\
2
2
Fin space
mm
1.5
1.6
Length × Height
mm
845×1,092
837×1,100
Number of circuits
\
8
8
Refrigerant
pipe
Liquid side / Gas side
mm
Φ9.52/Φ19
Φ9.52/Φ19
Max. pipe length
m
30
30
Max. difference in level
m
20
20
Connection
wire
Power wire
\
4×4.0mm
2
+1×2.5mm
2
(Ground)
4×10.0mm
2
+1×6.0mm
2
(Ground)
Signal wire
\
1×1.0mm
2
1×1.0mm
2
Dimension (W×H×D)
mm
987×1,167×400
987×1,167×400
Packing (W×H×D)
mm
1,032×1,307×443
1,032×1,307×443
Net / Gross weight
kg
91.6/102
96.6/107
Notes:
Nominal cooling capacities are based on the following conditions:
Indoor temperature: 27°CDB, 19°CWB; Outdoor temperature: 35°CDB, 24°C WB; Equivalent refrigerant pipe: 7.5m.
