Midea MCD-36HRN1-R1 - Specification

Light Commercial R410A on-off DM17-01.01.08en
117
1. Specification
Model MOBA30U-12HN1-Q MOBA30U-18HN1-Q MOCA30U-24HN1-Q
Power supply V-ph-Hz 220-240-1-50 220-240-1-50 220-240-1-50
Max. input consumption W 1800 2950 3450
Max. input current A 8.5 15 18
Compresso
r
Model ASM140V1VFT PA215M2AS-7KTL6 PA291X3CS-4MTM1
Type ROTARY ROTARY ROTARY
Brand GMCC GMCC GMCC
Capacity Btu/h 13853/13853 21325 24498/24669
Input W 955/995 1525 2395/2540
Rated
current(RLA)
A 4.35/4.2 6.85 11.55/12.25
Locked rotor
Amp(LRA)
A 25 / 59
Thermal protector
position
INTERNAL INTERNAL INTERNAL
Capacitor μF 35UF/450V 50UF/450V 60UF/450V
Refrigerant oil ml ESTER OIL VG74/350 ESTER OIL VG74/620
ESTER OIL VG74 ·
950
Outdoor fan
motor
Model YKT-32-6-203L YKT-48-6-206 YKT-75-6-200L
Qty 1 1 1
Input W 72.5/67 91.8/79.2 144
Capacitor μF 2.5UF/450V 3UF/450V 3UF/450V
Speed r/min 850/770 890/830 860
Outdoor coil
Number of rows 1.6 2 2
Tube pitch(a)* row
pitch(b)
mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.4 1.4 1.2
Fin type Hydrophilic aluminium Hydrophilic aluminium Hydrophilic aluminium
Tube outside
dia.and type
mm Φ7,innergroove tube Φ7,innergroove tube Φ7,innergroove tube
Coil length *
height * width
mm
755x504x13.37+475x504
x13.37
755x504x26.74 730x651x26.74
Number of circuits 4 4 6
Outdoor noise level (sound
pressure)
dB(A) 59 62 62
Throttle type capillary capillary Throttle Valve
Outdoor
unit
Dimension(WxDx
H)
mm 770x300x555 770x300x555
845x363x702
Packing(WxDxH) mm 900x345x585 900x345x585 965x395x755
Net/Gross weight kg 30.5/32.9 36.5/38.8 52.7/56.1
Refrigerant
type/Q-ty
Type R410A R410A R410A
Charged volume kg 1.1 1.5 1.8
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas
side
mm(inc
h)
Φ6.35/Φ12.7(1/4"/1/2") Φ6.35/Φ12.7(1/4"/1/2")
Φ9.52Φ15.9(3/8"/5/8"
)
Max. pipe length m 18 25 25
Max. difference in
level
m 8 15 15
Ambient
temperature
Cooling Ԩ
18-43 18-43 18-43
Heating Ԩ
-7-24 -7-24 -7-24
