Midea MCD-36HRN1-R1 - Page 69

Light Commercial R410A on-off DM17-01.01.08en
69
Indoor Model MHG-36HWN1-R1 MHG-48HWN1-R MHG-60HWN1-R
Outdoor Model MOD31U-36HN1-R MOU-48HN1-R MOU
A
-60HN1-R
Power supply V,Hz,Ph 380~420,50,3 380~420,50,3 380-415,50,3
Cooling
Capacity Btu/h 36000 49000 56000
Input W 3750 5128 6500
Current A 6.3 9 11,2
EER W/W 2,81 2,8 2,53
Heating
Capacity Btu/h 36000 52000 62000
Input W 3300 4220 5300
Current A 5.6 7,40 9,20
COP W/W 3,20 3,61 3,43
Indoor fan
motor
Model
YKSS-210-4-1 YSK250-4C YSK250-4C
Qty 1 1 1
Input W 420/340/300 480/420/360 588/480/420
Capacitor uF/ V 10UF/450V 10μF/450V 10μF/450V
Speed (Hi/Mid/Lo) r/min 1200/1090/980 750/705/655 860/750/705
Indoor coil
Number of rows 4.0 3 3
Tube pitch(a)×row
pitch(b)
mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.3 1.3 1,3
Fin type
Hydrophilic
aluminium
Hydrophilic aluminium Hydrophilic aluminium
Tube outside diameter
.and type
mm Φ7,innergroove tube Φ7,innergroove tube Φ7,innergroove tube
Coil
length×height×width
mm 990x252x53.48
1055x357x40.11
1055x357x40.11
Number of circuits 6 8 8
Indoor air flow (Hi/Med/Lo) m
3
/h 2059/1819/1667 2809/2554/2272 3150/2809/2554
ESP
Rated Pa 37 50 50
Range Pa 0-160 0-200 0-200
Indoor noise level (Hi/Med/Lo) dB(A) 54.6/51.6/49.6 51/49/46 52/50/48
Throttle type / / /
Indoor unit
Dimension (W×D×H) mm 1100×525×270 1200x625x380 1200x625x380
Packing (W×D×H) mm 1335×555×340 1485×675×450 1485×675×450
Net/Gross weight kg 33.7/39.3 46/52.3 45.9/52.2
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe dia ODΦ25 ODΦ25 ODΦ25
Refrigerant
piping
Liquid side/ Gas side mm Φ9.52/Φ19(3/8"/3/4") Φ12.7/Φ19 Φ12.7/Φ19
Controller standard KJR-12B/DP(T)-E-2 KJR-12B/DP(T)-E-2 KJR-12B/DP(T)-E-2
Operation temperature
Ԩ
17~30 17~30 17~30
Room
temperature
Cooling Ԩ
17～32 17~32 17~32
Heating
Ԩ
0～30 0~30 0~30
