Midea MCHSU-24PHH2

MCHSU-09PHH2，MCHS-12PSH1，MCHSU-12PHH2，
No.
Part name Procedures Remarks
1 Panel plate
How to remove the panel
plate.
1) Stop operation of
the air conditioner and
turn “OFF” the power
breaker.
2)Remove the big handle
first, and then remove the
top panel(3 screws).
3) Remove the screws of
front panel(7 screws)
(4) Remove the screws of
the right side panel(11
screws)
Screws of top panel (3 screws, 1 screw is under the big
handler)
3 screws
of the big handler
7 screws of front panel
②
③
④
