Part 2 - Component Layout and Refrigerant Circuits
MDV-400(14)W/D2RN1T(C) / MDV-450(16)W/D2RN1T(C)
Figure 2-1.3: MDV-400(14)W/D2RN1T(C) / MDV-450(16)W/D2RN1T(C) top view
Figure 2-1.4: MDV-400(14)W/D2RN1T(C) / MDV-450(16)W/D2RN1T(C) front view
Electronic
expansion valve
Solenoid valve
Solenoid valve
Electronic
expansion valve
High pressure switch
High pressure sensor
DC fan motor
Four-way valve
Four-way valve
Four-way valve
Outdoor ambient
temperature sensor
DC fan motor
Unloading valve
Low pressure switch
DC inverter compressor
High pressure switch
DC inverter compressor
