Midea MDV-615(22)W/D2DN1(B) User Manual

R410A All DC Inverter V4+S Series 60Hz MCAC-VTSM-2015-09
18 Specifications & Performances
1. Specifications
Outdoor unit specifications
Independent unit specifications
HP
8
10
12
Model
MDV-252(8)W/D2DN1(B)
MDV-280(10)W/D2DN1(B)
MDV-335(12)W/D2DN1(B)
Power supply
V/Ph/Hz
220/3/60
Cooling
Capacity
kW
25.2
28.0
33.5
kBtu/h
86.0
95.5
114.3
Power input
kW
5.88
7.05
8.79
EER
4.29
3.97
3.81
Heating
Capacity
kW
27.0
31.5
37.5
kBtu/h
92.1
107.5
128.0
Power input
kW
6.15
7.55
8.99
COP
4.39
4.17
4.17
Connectable
indoor unit
Total capacity
50~130% of outdoor unit capacity
Max. quantity
13
16
20
Compressor
Type
DC inverter
Model
E655DHD-65A2YG
E405DHD-36A2YG+
E655DHD-65A2YG
Brand
Hitachi
Quantity
1
1
2
Crankcase heater
W
27.6×2
27.6×2
27.6×4
Refrigerant oil type
FVC68D
Refrigerant oil charge
ml(gal.)
500
500
500×2
Fan motor
Type
DC motor
Model
WZDK560-38G(B)
Brand
Panasonic&Nidec
Quantity
1
1
2
Insulation class
E
Safe class
IPX4
Input
W
534
534
272×2
Output
W
420
420
210×2
Static pressure
Pa(in. W.G.)
0-20(0-0.08) (default)
Pa(in. W.G.)
0-40(0-0.16) (customized)
0-60(0-0.24) (customized)
Fan
Material
Plastic
Type
Axial
Quantity
1
1
2
Outdoor coil
Number of rows
2
Tube pitch(a)×
row pitch(b)
mm(in.)
22×19(7/8×3/4)
Fin spacing
mm(in.)
1.6(1/16)
Fin type
Hydrophilic aluminum
Tube outside diameter
mm(in.)
Ф7.94(Ф5/16)
Tube type
Inner-grooved
Coil length × height
mm(in.)
1985×1232(78-5/32×48-1/2)
2270×1232(89-3/8×48-1/2)

Midea MDV-615(22)W/D2DN1(B) Specifications

General

Brand	Midea
Model	MDV-615(22)W/D2DN1(B)
Category	Air Conditioner
Language	English
