MCAC-VTSM-2015-09 R410A All DC Inverter V4+S Series 60Hz
Specifications & Performances 35
4. Piping diagrams
8-10HP
Compressor
INVERTER
Oil Separator
Low Pressure
Receiver
unloading valve
Heat Exchanger
DC Fan
EXV A
SV6
SV5
ST 1
SV 4
SV 2
8~10HP
Oil Balance
Stop Valve
(Low Pressure)
Stop Valve
(High Pressure)
HPS
High Pressure
Switch
SENP
High Pressure
Sensor
LPS
Low
Pressure
Switch
12HP
Compressor
INVERTER
Compressor
INVERTER
Oil Separator
Heat Exchanger
DC Fan
EXV A
SV6
SV5
ST 1
unloading valve
SV4
SV2
Oil Balance
Stop Valve
(Low Pressure)
Stop Valve
(High Pressure)
Low Pressure
Receiver
12HP
HPS
High Pressure
Switch
SENP
High
Pressure
Sensor
LPS
Low
Pressure
Switch
