3)Disconnect the
connector for fan motor
from the electronic control
board.
4)Remove the four fixing
screws of the
fan motor.
Then remove the fan
motor.
○
3
○
4
compressor
T3,T4,T5 sensor
Motor
Electronic expansion valve
4 way valve
③
