Midea MGA-D16/SN1 User Manual

R410A Mini Split Chiller 50Hz MCAC-ATSM-2014-01
24
Model
MGA-D14/SN1
Ta. U.R.87% (°C)
Tw (°C)
35
40
45
50
-5
Pt (kW)
10.4
10.5
10.6
—
Pa (kW)
4.0
4.4
4.9
—
Pat (kW)
4.8
5.2
5.7
—
Qc (m
3
/h)
1.9
1.9
1.9
—
△ Pc (kPa)
25.8
27.2
27.0
—
0
Pt (kW)
13.1
13.0
13.0
12.9
Pa (kW)
4.0
4.4
4.9
5.4
Pat (kW)
4.8
5.2
5.7
6.1
Qc (m
3
/h)
2.3
2.3
2.3
2.3
△ Pc (kPa)
21.1
21.1
21.0
21.0
7
Pt (kW)
16.2
16.1
16.0
15.9
Pa (kW)
4.1
4.5
5.0
5.5
Pat (kW)
4.9
5.3
5.8
6.3
Qc (m
3
/h)
2.8
2.8
2.8
2.8
△ Pc (kPa)
31.2
31.1
31.0
31.0
10
Pt (kW)
17.6
17.5
17.4
17.4
Pa (kW)
4.2
4.6
5.1
5.6
Pat (kW)
5.0
5.4
5.9
6.4
Qc (m
3
/h)
3.1
3.1
3.1
3.1
△ Pc (kPa)
36.4
36.2
36.0
35.9
15
Pt (kW)
19.8
19.7
19.6
19.4
Pa (kW)
4.3
4.7
5.2
5.7
Pat (kW)
5.1
5.5
6.0
6.5
Qc (m
3
/h)
3.5
3.5
3.5
3.5
△ Pc (kPa)
45.4
45.2
45.0
44.9
Remark:
Ta: outside air temperature (°C )
Tw : evaporator water outlet temperature (°C)
Pt: heating capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qc: condenser water flow (m
3
/h)
ΔPc: evaporator pressure drop (kPa)
— : conditions outside of operating limits
