Midea MGA-D16/SN1 User Manual

MCAC-ATSM-2014-01 R410A Mini Split Chiller 50Hz
25
Model
MGA-D16/SN1
Ta. U.R.87% (°C)
Tw (°C)
35
40
45
50
-5
Pt (kW)
11.5
11.4
11.3
—
Pa (kW)
4.1
4.5
5.0
—
Pat (kW)
4.9
5.3
5.8
—
Qc (m
3
/h)
2.0
2.0
2.0
—
△ Pc (kPa)
25.0
25.0
24.8
—
0
Pt (kW)
14.2
14.1
14.0
13.9
Pa (kW)
4.2
4.6
5.1
5.6
Pat (kW)
5.0
5.4
5.1
5.6
Qc (m
3
/h)
5.0
5.4
5.9
6.4
△ Pc (kPa)
20.2
20.1
20.0
19.9
7
Pt (kW)
17.2
17.1
17.0
16.9
Pa (kW)
4.3
4.7
5.2
5.7
Pat (kW)
5.1
5.5
6.0
6.5
Qc (m
3
/h)
2.9
2.9
2.9
2.9
△ Pc (kPa)
30.2
30.1
30.0
30.0
10
Pt (kW)
18.7
18.6
18.5
18.4
Pa (kW)
4.4
4.8
5.3
5.8
Pat (kW)
5.2
5.6
6.1
6.6
Qc (m
3
/h)
3.2
3.2
3.2
3.2
△ Pc (kPa)
35.4
35.2
35.0
34.8
15
Pt (kW)
21.0
20.9
20.8
20.7
Pa (kW)
4.5
4.9
5.4
5.9
Pat (kW)
5.3
5.7
6.2
6.7
Qc (m
3
/h)
3.6
3.6
3.6
3.6
△ Pc (kPa)
46.2
45.6
45.0
44.4
Remark:
Ta: outside air temperature (°C )
Tw : evaporator water outlet temperature (°C)
Pt: heating capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qc: condenser water flow (m
3
/h)
ΔPc: evaporator pressure drop (kPa)
— : conditions outside of operating limits

Midea MGA-D16/SN1 Specifications
