MCAC-2008-11 Air-cooled Modular Chiller
28
No. Part Name Quantity No. Part Name Quantity
1 Top cover 1 31.1 Pressure controller 1
2 Axial flow fan 1 32 Suction pipe ass'y D 1
3 Motor 1 32.1 Pressure controller 1
4 Top cover 1 33 Accumulator cylinder 2
5 Motor bracket 2 34 Middle partition plate 1
6 Rear cover 1 35 Compressor 1
7 Side board 2 36 Compressor 1
8 Side sealed board 4 37 Clapboard supporting board 3
9 Front cover 1 38 Condenser ass'y 1
10 Cover board 2 38.1 Temp sensor ass'y 1
11 Drainage pan 1 38.2 Temp sensor ass'y 3
12 Drainage pan holder 2 39 Cover 1
13 Clamp 1 40 E-part box ass'y 1
14 Holder for Plate Heat-exchanger 1 40.1 E-part box 1
15 Sealed board 1 40.2 Transformer 1
16 Cover 2 40.3 Main controller ass'y 1
17 Rear—front net 2 40.4 Relay 2
18 Water Inlet/Outlet pipe ass'y 1 40.5 Contactor 2
19 Holder ring 2 40.6 Compressor capacitor 1
20 Support board 2 40.7 Wire joint 1
21 Cover 1 40.8 Wire joint 4
22 4-way valve ass'y 1 40.9 Wire joint 1
22.1 Muffler 1 40.10 Wire joint, 3p 1
22.2 4-way valve 1 40.11 Wire joint, 4p 1
22.3 Pipe joint 2 41 E-Part box cover 1
22.4 Strainer 3 43 Protecting water box 1
22.5 Pressure controller 1 44 Sealed board ass'y 2
22.7 Discharge temp sensor 1 45 Condenser ass'y 1
23 4-way valve ass'y 1 45.1 Temp sensor ass'y 3
23.1 4-Ways valve solenoid 1 46 Motor holder 2
23.2 Strainer 1 47 Heat-exchanger ass'y 1
23.3 Pressure controller 1 47.1 Electronic expansion valve 2
23.4 Muffler 1 47.2 Strainer 2
23.5 4-way valve 1 47.3 Plate Heat-exchanger 1
23.6 Pipe joint 3 47.4 EEV solenoid 2
23.7 Discharge temp sensor 1 48 Sealed board ass'y 1
24 Bracket ass'y 2 49 Connecting pipe 1
25 Base ass'y 1 50 Connecting pipe ass'y 1
26 Bracket ass'y 2 51 4-way valve connection pipe 1
27 Strengthen bracket 6 52 Connecting pipe ass'y 1
28 Base bracket 1 52.1 Strainer 1
29 Base bracket 1 52.2 Pressure-relief-valve 1
30 Base ass'y 1 53 R410A 3.5×2kg
31 Suction pipe ass'y A 1
