MCAC-2008-11 Air-cooled Modular Chiller
30
8 4-way valve ass'y 1 36.11 Wire joint, 4p 1
8.1 Muffler 1 37 Bracket ass'y 2
8.2 4-way valve 1 38 Base ass'y 1
8.3 Pipe joint 3 39 Bracket ass'y 2
8.4 Strainer 1 40 Drainage pan holder 4
8.5 Pressure controller 1 41 Connecting pipe ass'y 1
8.6 EEV solenoid 1 42 Connecting pipe 1
8.7 Discharge temp sensor 1 43 4-way valve connection pipe 1
9 Suction pipe ass'y D 1 44 Heat-exchanger plate 1
9.1 Pressure controller 1 44.1 Plate Heat-exchanger 1
10 4-way valve ass'y 1 45 Heat-exchanger ass'y 1
10.1 4-Ways valve solenoid 1 45.1 Electronic expansion valve 2
10.2 Strainer 1 45.2 Strainer 2
10.3 Pressure controller 1 45.3 Plate Heat-exchanger 1
10.4 Muffler 1 46 Middle partition plate 1
10.5 4-way valve 1 47 Sealed board 1
10.6 Pipe joint 3 48 Water Inlet/Outlet pipe ass'y 1
10.7 EEV solenoid 1 49 Holder ring 4
10.8 Discharge temp sensor 1 50 Side sealed board 4
11 Clapboard supporting board 6 51 Cover 2
12 Motor bracket 4 52 Front cover 1
13 Drainage pan 2 53 Top cover 1
14 Cover board 4 54 Support board 4
15 Side board 2 55 Rear—front net 4
16 Compressor cover bracket 2 56 Sealed board ass'y 2
17 Cover 2 57 Cover 4
18 4-way valve connection pipe ass'y 1 58 Sealed board ass'y 1
19 4-way valve connection pipe ass'y 1 59 Sealed board ass'y 1
20 Connecting pipe ass'y 1 60 Condenser side board 1
21 Connecting pipe ass'y 1 61 Condenser side board ass'y 1
22 Connecting pipe ass'y 1 62 Motor holder 4
22.1 Strainer 1 63 Condenser ass'y 2
22.2 Pressure-relief-valve 1 63.1 Temp sensor ass'y 5
23 Protecting water box 2 63.2 Temp sensor ass'y 1
24 Rear cover 1 64 Condenser ass'y 2
25 E-Part box cover 2 64.1 Temp sensor ass'y 6
26 Base ass'y 1 64.2 Temp sensor ass'y 1
27 Strengthen bracket 8 65 Condenser Partition board ass'y 1
28 Compressor 1 66 Middle supporting board 2
29 Compressor 3 67 R410A 3.5×4Kg
30 Base ass'y 1
