Midea MGB-D30W/RN1

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
80
No. Part Name
Qty BOM code No. Part Name Qty BOM code
19
Electrical box ass'y
1 203390190029 42
Cover
1 201295300096
19.1
Electronic installation board
1 201290190227 43
Left-side board ass'y
1 201290190232
19.2
Dual Relay
1 202300830544 44
Rear cover
1 201290190223
19.3
Compressor capacitor
1 202401000410 45
Front cover
1 201290100235
19.4
Low temp. cooling module
ass'y
1 201390190028 46
Top cover
1 201290140111
19.5
Relay
1 202300800003 47
Maintenance window in the
bulkhead cover
1 201290501495
19.6
Contactor
2 202300850043 48
Welding part of middle
separation board
1 201290190205
19.7
Contactor
1 202300800110 49
Outlet pipe fixed base
1 201290190287
19.8
Three-phase power
protection devices
1 202301600518 50
Net
2 201290190118
19.9
Wire joint
4 202301450122 51
Clapboard supporting board
3 201295010094
19.10
Wire joint
1 202301450110 52
About clapboard
1 201295500014
19.11
Wire joint
1 202301450132 53
Top cover
1 201195300051
19.12
Wire joint,11p
1 202301400365 54
B components of the left seal
plate condenser
1 201290190123
19.13
Outdor main board ass'y
1 201390190026 55
Axial flow fan
1 201200300013
19.14
Transformer
1 202300900109 56
Motor
1 202400401168
19.15
Outdoor current detection
board ass'y
1 201390190020 57
Motor bracket bonding parts
2 201290590191
