Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
10
Note: Please refer to the water flow volume in the above table strictly to design and install.
All the above data is measured base on the following working condition:
1. cooling mode under normal working condition: water flow 0.172 m
3
/(h•kW), outlet water temperature of chilled water is
7℃,air inlet temperature of condenser is 35℃;
2. heating mode under normal working condition: water flow 0.172 m
3
/(h•kW), outlet water temperature of chilled water is
45℃,air inlet temperature of condenser is DB/WB 7/6℃.
Operation weight kg 400
Connection wire
Power wire mm
2
×No. 10×4+10×1
Signal wire mm
2
×No. 0.75×3-core
Control type Wired controller
Safety protection device
1) Protection for over-high discharge pressure.
2) Protection for over-low suction pressure.
3) Power supply phase sequence protection.
4) Anti-frozen protection in cooling mode.
5) Anti-frozen protection in Winter.
6) Protection for compressor over current.
7) Protection for compressor overload.
8) Outlet and inlet water temperature difference protection.
9) Compressor discharge temp. protection.
10) Water flow cut-off protection.
11) Sensor malfunction protection.
Noise level(semi-anechoic ) dB(A) 65
Operation water temp ℃ Cooling：5～17 Heating：45～50
Ambient temp ℃
Cooling：10～46
Heating：-10～21
