Midea MGB-F60W/RN1 User Manual

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
9
3. Specification
Model MGB-F25W/RN1 MGB-F30W/RN1
Cooling Capacity
kW 28 30
Btu/h 95,500 102,300
Heating Capacity kW 29.5 32
Power supply V/Ph/Hz 380-415/3/50
Power supply
Manual switch A 50
Fuse A 36
Compressor
Type Scroll (constant speed)
Quantity Pieces 2
Model ZP67KCE-TFD-522
Brand Copeland
Capacity W 16200×2
Input W 5200×2
Rate current(RLA) A 9.1×2
Locked rotor Amp(LRA) A 74×2
Power input
Cooling kW 9.3 10.0
Cooling rated current A 14.6 16.3
Heating kW 9.2 9.8
Heating rated current A 14.3 16
Max. Input consumption A 12.6
Max. Current A 21.8
Refrigerant
Type R410a
Weight kg 3.5×2
Refrigerant control EXV+ capillary throttle
Condenser
(Air side)
Air side heat-exchanger type Copper-fin-coil
Quantity of fan motor Pieces 1
Air flow volume ×10
3
m
3
/h 12
Fan motor input kW 0.3
Evaporator
(Water side)
Water side heat-exchanger type Tube in tube
Water resistance loss kPa 60
Water inlet/outlet pipeline inside
normal diameter
mm DN40
inch 1-1/2”
Water flow volume m
3
/h 4.4 5.2
Max. Pressure MPa 1
Water pipe connection type Flexible joint
Dimension
Net(W×H×D)
mm
1514×1865×841
inch
59.6×73.4×33.1
Packing(W×H×D)
mm
1590×2065×995
inch
62.6×81.3×39.2
Weight Net weight kg 380
