Midea MGB Series

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
92
No. Part Name
Qty BOM code No. Part Name Qty BOM code
17
Base weld parts
1 201290100286 50
A2 machine back to the tube
components
1 201690191373
18
Compressor
4 201402300130 50.1
Pressure controller
1 202301800845
19
Storage tank bottom II weld
installation
1 201290100264 51
B1 machine back to the tube
components
3 201690191375
20
Compressor installed base II
weld
1 201290100273 51.1 Pressure controller 1 202301800844
21 Reinforcement board 4 201290100247 52
A2 four-way valve assembly
machine
1 201690191352
22
Triangle reinforcement ass'y
8 201290100218 52.1
4-way valve
1 201600600110
23
Piping support-unit
2 201290100272 52.2
Pressure controller
1 202301800842
24
Vapor-liquid separator
4 201601100111 52.3
Pressure controller
1 202301800843
25
Shell and tube evaporator
1 201790190019 52.4
Pipe joint
2 201601200004
26
Storage tank bottom I weld
parts installation
1 201290100265 53
I sealed connector condenser
2 201290100261
27
Compressor installed base I
weld
1 201290100274 54
Roof rack beams II
1 201290100276
28
Vertical beams in the frame
2 201290100256 55
Top cover
4 201195300051
29
I left panel
3 201290100270 56
I beam roof rack
1 201290100277
30
B2 machine evaporator inlet
pipe assembly
1 201690191293 57 Vertical beam roof rack 2 201290100287
30.1 Electronic expansion valve 1 201601300018 59
Total water temperature mouth
components
1 201690101220
31
A2 machine evaporator inlet
pipe assembly
1 201690191291 61
Coil temp sensor ass'y
2 202301300081
31.1
Electronic expansion valve to
take over
1 201690101166 63
Pipe temperature sensor
assemblies
1 202301300082
32
B1 Evaporator inlet pipe
assembly machine
1 201690191295 64 Room temp sensor ass'y T41 2 202301300403
32.1 Electronic expansion valve 1 201601300018 66
Discharge temperature
controller
4 202301610049
33
A1 machine evaporator inlet
pipe assembly
1 201690191294 67
Electrical heating belt
compression
4 202403101357
33.1
Electronic expansion valve
1 201601300018 68
Four-way valve coil
2 201600600235
34
B1 machine four-way valve
assembly
1 201690191354 69 Four-way valve coil 2 201600600237
34.1
4-way valve
1 201600600110 70
Electronic expansion valve coil
4 201601300544
34.2
Pressure controller
1 202301800842 71
Refrigerant
28 200500100021
34.3
Pressure controller
1 202301800841 72
Wire controller
1 203355100210
34.4 Pipe joint 2 201601200004 73
Pipe temperature sensor
assemblies
3 202301300097
35
A1 Machine four-way valve
assembly
1 201690191356 76 Coil temp sensor ass'y 4 202301300400
35.1 4-way valve 1 201600600110 81
Pipe temperature sensor
assemblies
1 202301300478
35.2
Pressure controller
1 202301800841
