Midea MGB Series

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
98
No. Part Name
Qty BOM code No. Part Name Qty BOM code
24
Outlet pipe ass'y II of
condenser
1 201690191445 74 Seal plate condenser 8 201290100382
25
Wire casing I
1 201290190279 75 Motor 2 202400800952
26
Cover of wire casing I
1 201290190280 76 Axial flow fan 8 201200300013
27
Shell-tube heat exchanger
1 201790190021 77 Motor bracket bonding parts 16 201290100375
28
Installation base welding
parts of compressor
4 201290190255 78 Part B condenser 4 201590100022
29
Inclined support II
1 201290190249 79
A machine Condenser Parts
4 201590100021
30 Pipe support I 1 201290190263 80
B fixed plate with pieces of
condenser
4 201290108635
31 Pipe support II 2 201290190262 81
A fixed plate with pieces of
condenser
4 201290108634
32 Grille fixed board I 4 201290190251 82
Welding parts water tray
4 201290100398
33 Front grille 8 201290100348 83
Cover II of electrical box
1 201290190275
34 Fixed board II of grille 2 201290190250 84
Cover I of electrical box
1 201290190276
35 Compreesor 8 201402300210 85
Support board of electrical
box
2 201290190271
37 Liquid separator 4 201601100165 86
Output pipe of evaporator
1 201690191452
38 Bottom column 4 201290190247 87
Output pipe ass'y of
evaporator(A)
1 201690191443
39 Beam 2 201290190246 88
Output pipe ass'y of
evaporator(B)
1 201690191441
40 Front Panel 5 201290100368 89
Output pipe ass'y of
evaporator(C)
1 201690191439
41 Wire casing 1 201290190277 90
Output pipe ass'y of
evaporator(D)
1 201690191437
42 Cover of wire casing II 1 201290190278 91
Suction pipe ass'y of
compressor
4 201690191462
43
Fixed board of drainage
8 201290190243 92
Suction pipe III
4 201690191450
45
Panel fasteners II
8 201290100372 93
Oil balance pipe ass'y I
4 201690191477
46
Inclined support I
1 201290190248 94
Reinforcing board
1 201290190284
47
Wire support
3 201290190270 95
Refrigerant
60 200500100021
48
Wiring bridge
3 201290190264 96
Oil balance pipe ass'y II
4 201690191478
49
I sealed connector
condenser
4 201290100378 97 Four-way valve coil 4 201600600517
50
Condenser sealed connector
II
4 201290100381 99
Electronic expansion valve
coil
4 201601300544
52
About the protective screen
4 201290100347 100
Total water temperature
mouth components
1 201690101220
53
Upper beam
2 201290190252 101
Target flow-volume controller
1 202301820013
54
Roof rack beam welding
parts
3 201290100359 102
Electrical heating belt
compression
8 202403100066
55
Vertical beam roof rack
2 201290100383
