Specification MCAC-TSM-2008-02
10 Installation
Model MGC-F10W/SN1 MGC-F12W/SN1
Power supply V-Ph-Hz
380-415 , 3, 50 380-415 , 3, 50
Capacity kW
10.5 12
Cooling
Input W
3930 4410
Capacity kW
12 14
Heating
Input W
4240 4643
Max. input consumption W
4400 5000
Max. input current A
8.3 9.1
Starting current A
45 66
Model
ZP50K3E-TFD-522 C-SBN373H8D
Type
SCROLL SCROLL
Brand
Copeland SANYO
Capacity Btu/h
42300 48109.2
Input W
4100 4750
Rated current (RLA) A
7.3 8.22
Locked rotor Amp (LRA) A
64 66
Thermal protector
Inner Inner
Capacitor uF
/ /
Compressor
Refrigerant oil ml
POE OIL，1952 FV68S, 1700
Model
YDK100-6A(×2) YDK100-6A(×2)
Type
AC motor AC motor
Brand
Welling Welling
Input (Hi/Lo) W
185/120 185/120
Capacitor uF
5uF/450V 5uF/450V
Outdoor fan
motor
Speed (Hi/Lo) r/min
860/610 860/610
Number of rows
2 2
Tube pitch(a)× row pitch(b) mm
22×19.05 22×19.05
Fin spacing mm
1.5 1.5
Fin type
Hydrophilic aluminium foil Hydrophilic aluminium foil
φ7.94 φ7.94
Tube outside dia. and type mm
Inner grooved copper tube Inner grooved copper tube
Coil length ×height × width mm
807×1188×38.1 945×1188×38.1
Outdoor coil
Number of circuits
7 7
Type
RL25/8.5 RL25/8.5
Input (H/M/L) W
210/175/120 210/175/120
Water pump
Outdoor air flow m
3
/h
6465/4270 6470/4280
Throttle
Capillary Capillary
Outdoor noise level (sound pressure) dB(A)
58/48 59/49
Water flow volume m
3
/h
1.72 2.0
The plate heat-exchanger water pressure drop kpa
44 40
The Max. and Min. water inlet pressure kpa
500/150 500/150
Dimension (W×H×D) mm
940×1245×360 1070×1249×420
Packing (W×H×D) mm 1058×1380×438 1188×1385×498
Outdoor unit
Net/ Gross weight kg 131/139 137/145
Type R410A R410A
Refrigerant
type/Quantity
Charged volume g 2700
3000
Power wiring mm
2
5×2.5 5×2.5
Connection
wiring
Signal wiring (connect to wired
control)
mm
2
3×1.0 3×1.0
Pipe diameter Water inlet/outlet mm
R5/4 R5/4
Control
Wired controller Wired controller
Ambient temp． ℃
Cooling: 10℃~43℃; Heating: -15-24℃
Nominal capacity is based on the following conditions:
1. Condenser air in 35℃. Evaporator water in/out 12/7℃
2. Evaporator air in 7℃ 85% R.H., Condenser water in/out 40/45℃
3. The two types of oil are equivalents
4. At 1m in open field fan side (sound pressure)
5. The maximum and minimum operating pressure values refer to the activation of the pressure switches
