MCAC-TSM-2008-02 Outdoor units
Outdoor units 11
Model MGC-F14W/SN1 MGC-F16W/SN1
Power supply V-Ph-Hz
380-415 , 3, 50 380-415 , 3, 50
Capacity kW
14 16
Cooling
Input W
4859 6430
Capacity kW
16.12 18
Heating
Input W
5218 6444
Max. input consumption W
6550 7700
Max. input current A
10.5 14.3
Starting current A
60 92
Model
C-SBN453H8D C-SBN523H8D
Type
SCROLL SCROLL
Brand
SANYO SANYO
Capacity Btu/h
56000 65510
Input W
5750 6750
Rated current (RLA) A
9.77 11.6
Locked rotor Amp (LRA) A
67 73
Thermal protector
Inner Inner
Capacitor uF
/ /
Compressor
Refrigerant oil ml
FV68S, 1600 FV68S, 1700
Model
YDK100-6A(×2) YDK100-6A(×2)
Type
AC motor AC motor
Brand
Welling Welling
Input (Hi/Lo) W
185/120 185/120
Capacitor uF
5uF/450V 5uF/450V
Outdoor fan motor
Speed (Hi/Lo) r/min
860/610 860/610
Number of rows
3 3
Tube pitch(a)× row pitch(b) mm
25.4×22 22×19.05
Fin spacing mm
1.5 1.6
Fin type
Hydrophilic aluminium foil Hydrophilic aluminium foil
φ9.53 φ7.94
Tube outside dia. and type mm
Inner grooved copper tube Inner grooved copper tube
Coil length ×height × width mm
718 ×1220×66 937×1188×57.15
Outdoor coil
Number of circuits
12 14
Type
RL25/8.5 RL25/8.5
Input (H/M/L) W
210/175/120 210/175/120
Water pump
Outdoor air flow m
3
/h
6500/4300 6550/4483
Throttle
Capillary Capillary
Outdoor noise level (sound pressure) dB(A) 60/50
60/51
Water flow volume m
3
/h
2.4 2.8
The plate heat-exchanger water pressure drop kpa
34 38
The Max. and Min. water inlet pressure kpa
500/150 500/150
Dimension (W×H×D) mm
1070×1249×420 1070×1249×420
Packing (W×H×D) mm
1188×1385×498 1188×1385×498
Outdoor unit
Net/ Gross weight kg 145/160
142/150
Type
R410A
R410A
Refrigerant
type/Quantity
Charged volume g
3600 4200
Power wiring mm
2
5×2.5 5×4.0
Connection wiring
Signal wiring (connect to wired
control)
mm
2
3×1.0 3×1.0
Pipe diameter Water inlet/outlet mm
R5/4 R5/4
Control
Wired controller Wired controller
Ambient temp． ℃
Cooling: 10℃~43℃; Heating: -15-24℃
Nominal capacity is based on the following conditions:
1. Condenser air in 35℃. Evaporator water in/out 12/7℃
2. Evaporator air in 7℃ 85% R.H., Condenser water in/out 40/45℃
3. The two types of oil are equivalents
4. At 1m in open field fan side (sound pressure)
5. The maximum and minimum operating pressure values refer to the activation of the pressure switches
