Midea MGC-F16W/SN1 User Manual

MCAC-TSM-2008-02 Outdoor units
Outdoor units 9
Model MGC-F09W/N1 MGC-F10W/N1
Power supply V-Ph-Hz
220-240, 1, 50 220-240 , 1, 50
Capacity kW 9.0
10.5
Cooling
Input W 3540
3614
Capacity kW 9.5
12
Heating
Input W 3820
4004
Max. input consumption W 4950
5500
Max. input current A 23.1
25.7
Starting current A 98
110
Model
ZP50K3E-PFZ-522 ZP50K3E-PFZ-522
Type
SCROLL SCROLL
Brand
Copeland Copeland
Capacity Btu/h
42600 42600
Input W
4100 4100
Rated current (RLA) A
19.5 19.5
Locked rotor Amp (LRA) A
123 123
Thermal protector
Inner Inner
Capacitor uF
80 80
Compressor
Refrigerant oil ml
1656 1656
Model
YDK100-6A(×2) YDK100-6A(×2)
Type
AC motor AC motor
Brand
Welling Welling
Input (Hi/Lo) W
185/120 185/120
Capacitor uF
5uF/450V 5uF/450V
Outdoor fan motor
Speed (Hi/Lo) r/min
860/610 860/610
Number of rows
3 3
Tube pitch(a)× row pitch(b) mm
25.4×22 25.4×22
Fin spacing mm
1.5 1.5
Fin type
Hydrophilic aluminium foil Hydrophilic aluminium foil
φ9.53 φ9.53
Tube outside dia. and type mm
inner groove tube inner groove tube
Coil length ×height × width mm
635×1220×66 635×1220×66
Outdoor coil
Number of circuits
6 6
Type
RL25/8.5 RL25/8.5
Input (H/M/L) W
210/175/120 210/175/120
Water pump
Outdoor air flow m
3
/h 6450/4250
6500/4300
Throttle
Capillary Capillary
Outdoor noise level (sound pressure) dB(A) 58/49 60/50
Water flow volume m
3
/h 1.54
1.74
The plate heat-exchanger water pressure drop kpa 42
44
The Max. and Min. water inlet pressure kpa
500/150 500/150
Dimension (W×H×D) mm
940×1245×360 940×1245×360
Packing (W×H×D) mm 1058×1380×438
1058×1380×438
Outdoor unit
Net/ Gross weight kg
138/145 138/145
Type R410A
R410A
Refrigerant
type/Quantity
Charged volume g
3000 3000
Power wiring mm
2
3×4.0
3×4.0
Connection wiring
Si
gna
l
w
i
r
i
ng
(
connect to w
i
re
d
control)
mm
2
3×1.0 3 ×1.0
Pipe diameter Water inlet/outlet mm
R5/4 R5/4
Control
Wired controller Wired controller
Ambient temp． ℃
Cooling: 10℃~43℃; Heating: -15-24℃
Nominal capacity is based on the following conditions:
1. Condenser air in 35℃. Evaporator water in/out 12/7℃
2. Evaporator air in 7℃ 85% R.H., Condenser water in/out 40/45℃
3. The two types of oil are equivalents
4. At 1m in open field fan side (sound pressure)
5. The maximum and minimum operating pressure values refer to the activation of the pressure switches
