MCAC-TSM-2008-02 Outdoor units
Outdoor units 49
No. Part Name Quantity No. Part Name Quantity
1 Condenser ass'y 1 23.2 Rubber gasket 1
2 Partition board ass'y 1 23.3 Electric heating strip 1
3 Expansion vessel 1 23.4 Plate Heat-exchanger 1
4 Accumulator cylinder 1 24 4-way valve ass'y 1
5 Drain Pump 1 24.1 4-way valve 1
6 Rear net clip 1 24.2 Pipe joint 2
7 Expansion tank joint pipe ass'y 1 24.3 4-Ways valve solenoid 1
7.1 Discharge valve 1 25 Fixing board 1
7.2 Discharge valve joint 1 26 Discharge pipe ass'y 1
7.3 Nut 1 26.1 Pressure controller 1
8 E-part box ass'y 1 27 Connecting pipe ass'y 1
8.1 E-part box 1 27.1 Water charge valve 1
8.2 Motor capacitor 2 27.2 Valve tie-in 1
8.3 Transformer 1 27.3 Safety valve 1
8.4 Power supply control board ass'y 1 27.4 Water-inlet pipe adapter 1
8.5 Controller 1 27.5 Nut 3
8.6 Filter board ass'y 1 27.6 Pipe joint 3
8.7 AC contactor 1 27.7 Pipe joint 2
9 Connecting pipe ass'y 1 27.7 Rubber gasket 2
9.1 Copper nut 2 28 Suction pipe ass'y 1
10 Top cover ass'y 1 28.1 Pressure controller 1
11 Water-inlet ass'y 1 29 Compressor 1
11.1 Water-inlet ass'y 1 30 Front panel 1
11.2 Nut 1 31 Base ass'y 1
11.3 Nut 1 32 Grille 2
11.4 Pipe joint 1 33 Axial flow fan 2
11.5 Pipe joint 1 34 Motor bracket ass'y 1
12 Front right clapboard ass'y 1 35 Motor 2
13 Rear right clapboard ass'y 1 36 Right cover ass'y 1
14 Urgency switch 1 37 Fixing ring 1
15 Hydraulic meter 1 38 Capillary ass'y 1
16 Expansion tank clamp 1 39 Liquid accumulator can ass'y 1
17 Valve 1 39.1 Liquid accumulator tank 1
18 Handle 2 40 Rear net 1
19 Drain pipe adapter 1 41 Temp. sensor ass'y 3
20 Display cover ass'y 1 42 Discharge temp sensor 1
21 Plate Heat-exchanger bracket 1 43 Temp. sensor ass'y 1
22 Left fixing board 1 44 Compressor electric heater 1
23 Heat-exchanger plate ass'y 1 45 Valve electric heater 1
23.1 Valve tie-in ass'y 1 46 Left clapboard 1
