MCAC-UTSM-2014-03 R410A 380~415V 3Ph 50Hz TempMaker Series Split AC
70
will gether on the air heat exchanger and lead to fault and water leak of the air conditioner.
In order to suppress noise effectively, install noise suppression and sound insulation
devices, especially in the noise-sensitive spaces such as meeting rooms.
For connection of the flange plane, use non-flammable canvas adapter to prevent
transmission of vibration. Use M6×20 screws (configured on site) for connection.
Key points of duct connection
MTB-76HWN1, MTB-96HWN1, MTB-120HWN1, MHB-76HWN1, MHB-96HWN1
View of air outlet side (Unit: mm)
