Midea MHC-V4W/D2N8-B

M thermal Mono
60 202005
Midea M thermal Mono Engineering Data Book
8 Sound Levels
8.1 Overall
Table 2-8.1: Sound pressure levels
1
Model name
dB
2
MHC-V4W/D2N8-B
45.0
MHC-V6W/D2N8-B
47.5
MHC-V8W/D2N8-B
48.5
MHC-V10W/D2N8-B
50.5
MHC-V12W/D2N8-B
53.0
MHC-V14W/D2N8-B
53.5
MHC-V16W/D2N8-B
57.5
MHC-V12W/D2RN8-B
53.5
MHC-V14W/D2RN8-B
54.0
MHC-V16W/D2RN8-B
58.0
Notes:
1. Sound pressure level is measured at a position 1m in front of the unit and (1+H)/2m (where H is the height of the unit) above the floor in a semi-anechoic
chamber. During in-situ operation, sound pressure levels may be higher as a result of ambient noise.
Figure 2-8.1: Sound pressure level measurement (unit: mm)
2. dB is the maximum value tested under the conditions below:
Outdoor air temperature 7⁰C DB, 85% R.H.; EWT 30⁰C, LWT 35⁰C. Free compressor frequency.
Outdoor air temperature 7⁰C DB, 85% R.H.; EWT 47⁰C, LWT 55⁰C. Free compressor frequency.
1000
(H+1000)
2
Front
