Connector
DRAIN REQUIREMENTS
DRAIN SYSTEM
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves and install
them as per the instruction below.
Condensing drain hose
Installation
1. Take the hose out of the holder.
2. Disconnect the hose from the water container inflow. (To assure
water tightness, there is tension between the hose and the inflow and
therefore an increased force is required for disassembly.)
3. Insert the drain hose and the external drainage hose into the connector.
4. Put the hose on the washing basin or floor drain. To assure the smooth
drainage, ensure the pipe is not folded.
Max . 78c m
