Page 9
Installation
Instructions
Installation Instructions
Preparation
NOTE:
All the illustrations in the manual are for explanation purpose only. Your machine may be slightly different.
The actual shape shall prevail. The unit can be controlled by the unit control panel alone or with the remote
controller. This manual does not include Remote Controller Operations, see the <<Remote Controller
Instruction>> packed with the unit for details.
Design Notice
In order to ensure the optimal performance of our products, the design specifications of the unit
and remote control are subject to change without prior notice.
rearfront
control panel
handle
(both sides)
horizontal louver blade
(swing automatically)
Caster
Panel
power plug socket
bottom tray
drain outlet
drain outlet
(only for pump
heating mode)
upper air filter
(behind the grille)
upper air intake
air hose
drain outlet
