Midea MRCT-200CWN1-R(C)

Rooftop ClimaCreator series DM16-01.01.27en
Service manual 11
Nominal ton (Ton) 8.5
Model MRCT-085CWN1-R(C)
Power Supply \ 380~415V, 3Ph, 50Hz
Cooling 1
Cooling capacity
Btu/h 102,000
kW 30.0
Power input kW 9.2
Cooling 2
Cooling capacity
Btu/h 80,700
kW 23.7
Power input kW 10.3
Max. input consumption kW 14.8
Max. current A 29.2
Performance
Indoor air flow CFM 3,500
ESP Pa Default: 80; 0~200
EER 1 Btu/h.W 11.1
EER 2 Btu/h.W 7.9
Indoor coil
Number of rows \ 4
Fin spacing mm 1.5
Fin type \ Hydrophilic aluminum fin
Tube diameter mm Φ7
Tube type \ Inner grooved copper pipe
Indoor fan
Type / Quantity \ Centrifugal / 1
Drive type \ Belt
Motor quantity \ 1
Motor model \ YE2-90L-4-1.5KW
Motor capacitor \ \
Motor input W \
Motor speed RPM 1,400
Compressor
Type / Quantity \ Scroll / 2
Model \ E604DH-59D2G E604DH-59D2G
Brand \ Hitachi Hitachi
Capacity W 15,390 15,390
Input W 5,130 5,130
RLA A 8.8 8.8
LRA A 62 62
Refrigerant oil ml 1,300 1,300
Outdoor coil
Number of rows \ 2.5
Fin spacing mm 1.5
Fin type \ Hydrophilic aluminum fin
Tube diameter mm Φ7
Tube type \ Inner grooved copper pipe
