Appendix: - Temperature sensor
Room / Pipe temperature sensor Resistance Valve (R25 = 10 kOhm±1%, B25/50 = 4100K±1%)
Temperature
(°C)
R
Max.
(KΩ)
R
Nor
.
(KΩ)
R
Min.
(KΩ)
Temperature Tolerance
(°C)
0 35.630 34.840 34.064 -0.41 0.42
1 33.741 33.011 32.292 -0.40 0.42
2 31.963 31.288 30.624 -0.39 0.41
3 30.290 29.666 29.051 -0.38 0.40
4 28.714 28.137 27.569 -0.38 0.39
5 27.230 26.697 26.172 -0.37 0.39
6 25.831 25.339 24.853 -0.36 0.38
7 24.513 24.058 23.609 -0.36 0.37
8 23.270 22.850 22.435 -0.35 0.36
9 22.097 21.710 21.327 -0.34 0.36
10 20.991 20.633 20.279 -0.33 0.35
11 19.947 19.617 19.290 -0.32 0.34
12 18.961 18.656 18.355 -0.32 0.33
13 18.030 17.749 17.471 -0.31 0.32
14 17.150 16.891 16.635 -0.30 0.32
15 16.318 16.080 15.844 -0.29 0.31
16 15.532 15.313 15.095 -0.29 0.30
17 14.788 14.587 14.386 -0.28 0.29
18 14.085 13.899 13.715 -0.27 0.28
19 13.419 13.249 13.079 -0.26 0.27
20 12.789 12.632 12.477 -0.25 0.27
21 12.191 12.048 11.906 -0.25 0.26
22 11.626 11.495 11.364 -0.24 0.25
23 11.090 10.970 10.850 -0.23 0.24
