DM16‐01.01.27en  RooftopClimaCreatorseries
128 Service manual
2. Airflow pressure drop
Model
Airflow pressure drop (inches W.C. [Pa])
15kW EHK 20kW EHK 30kW EHK 40kW EHK
MRCT-062CWN1-R(C)
0.32 [80] - - -
MRCT-075CWN1-R(C)
0.32 [80] - - -
MRCT-085CWN1-R(C)
- 0.32 [80] - -
MRCT-100CWN1-R(C)
- 0.32 [80] - -
MRCT-125CWN1-R(C)
- 0.32 [80] 0.40 [100] -
MRCT-150CWN1-R(C)
- 0.32 [80] 0.40 [100] -
MRCT-175CWN1-R(C)
- - - 0.64 [160]
MRCT-200CWN1-R(C)
- - - 0.64 [160]
MRCT-250CWN1-R(C)
- - - 0.64 [160]
MRCT-300CWN1-R(C)
- - - 0.64 [160]
3. Assemble
Step 1: Assembly the electrical heater duct to the supply opening by 10 pieces of screws.
