Midea MRCT-200CWN1-R(C)

Rooftop ClimaCreator series DM16-01.01.27en
Service manual 13
Nominal ton (Ton) 10
Model MRCT-100CWN1-R(C)
Power supply \ 380~415V, 3Ph, 50Hz
Cooling 1
Cooling capacity
Btu/h 120,000
kW 35.0
Power input kW 10.7
Cooling 2
Cooling capacity
Btu/h 100,200
kW 29.4
Power input kW 12.6
Max. input consumption kW 18.0
Max. current A 34.1
Performance
Indoor air flow CFM 4,100
ESP Pa Default: 90; 0~250
EER 1 Btu/h.W 11.2
EER 2 Btu/h.W 8.0
Indoor coil
Number of rows \ 4
Fin spacing mm 1.5
Fin type \ Hydrophilic aluminum fin
Tube diameter mm Φ7
Tube type \ Inner grooved copper pipe
Indoor fan
Type / Quantity \ Centrifugal / 1
Drive type \ Belt
Motor quantity \ 1
Motor model \ YE2-90L-4-1.5KW
Motor capacitor \ \
Motor input W \
Motor speed RPM 1,400
Compressor
Type / Quantity \ Scroll / 2
Model \ E654DH-65D2G E654DH-65D2G
Brand \ Hitachi Hitachi
Capacity W 17,100 17,100
Input W 5,700 5,700
RLA A 9.6 9.6
LRA A 66 66
Refrigerant oil ml 1,300 1,300
Outdoor coil
Number of rows \ 2.5
Fin spacing mm 1.5
Fin type \ Hydrophilic aluminum fin
Tube diameter mm Φ7
Tube type \ Inner grooved copper pipe
