Midea MRCT-200CWN1-R(C)

Rooftop ClimaCreator series DM16-01.01.27en
Service manual 21
Nominal ton (Ton) 20
Model MRCT-200CWN1-R(C)
Power supply \ 380~415V, 3Ph, 50Hz
Cooling 1
Cooling capacity
Btu/h 240,000
kW 70.0
Power input kW 22.6
Cooling 2
Cooling capacity
Btu/h 199,200
kW 58.4
Power input kW 25.1
Max. input consumption kW 33.0
Max. current A 66.9
Performance
Indoor air flow CFM 8,800
ESP Pa Default: 120; 0~375
EER 1 Btu/h.W 10.6
EER 2 Btu/h.W 7.9
Indoor coil
Number of rows \ 4
Fin spacing mm 1.3
Fin type \ Hydrophilic aluminum fin
Tube diameter mm Φ7
Tube type \ Inner grooved copper pipe
Indoor fan
Type / Quantity \ Centrifugal / 2
Drive type \ Belt
Motor quantity \ 1
Motor model \ YE2-132S-4-5.5KW
Motor capacitor \ \
Motor input W \
Motor speed RPM 1,440
Compressor
Type / Quantity \ Scroll / 2
Model \ ZP144KCE-TFD-522 ZP144KCE-TFD-522
Brand \ Copeland Copeland
Capacity W 35,400 35,400
Input W 10,800 10,800
RLA A 21.1 21.1
LRA A 144 144
Refrigerant oil ml 3,253 3,253
Outdoor coil
Number of rows \ 3
Fin spacing mm 1.5+1.5
Fin type \ Hydrophilic aluminum fin
Tube diameter mm Φ7+Φ7
Tube type \ Inner grooved copper pipe
Continued:
