DM16‐01.01.27en RooftopClimaCreatorseries
52 Service manual
MRCT-085CWN1-R(C)
Cooling capacity:
Gross Cooling Capacity
Ambient DB(°C) 29.4 35
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
2,450
23.9 89.1 77.0 8400.4 99.8 56.7 8825.0 103.6 34.9 9516.1 82.1 73.5 8742.2 95.7 54.7 8936.5 102.7 33.7 10074.2
26.7 91.0 78.7 8547.1 102.0 73.0 9000.1 106.0 49.7 9716.2 84.0 75.2 8923.9 97.9 71.1 9100.9 104.9 50.2 10320.9
29.4 93.1 80.5 8808.9 104.3 87.0 9247.5 108.3 62.4 10066.3 85.9 76.8 9185.6 100.1 87.3 9359.0 107.3 64.1 10631.9
32.2 95.2 82.3 9105.6 106.6 101 9597.6 110.6 76.0 10463.0 87.8 78.6 9479.0 102.3 100 9672.0 109.7 78.1 11035.4
3,500
23.9 91.5 82.5 8498.3 100.8 58.8 8865.5 104.0 35.4 9529.6 84.8 79.0 8846.8 99.0 57.7 9064.7 102.9 34.5 10084.3
26.7 93.6 84.4 8648.4 103.0 74.9 9040.6 106.3 50.5 9729.7 86.7 80.8 9028.5 102.0 75.4 9189.0 105.2 51.3 10331.0
29.4 95.7 86.3 8910.1 105.3 90.9 9288.0 108.6 63.8 10079.8 88.7 82.7 9293.6 104.3 91.9 9527.7 107.5 66.5 10642.0
32.2 97.8 88.2 9210.2 107.6 104 9638.1 111.0 77.2 10479.9 90.6 84.6 9590.3 105.8 101 9810.4 109.9 81.6 11045.5
4,200
23.9 93.9 87.6 8589.4 101.7 60.9 8902.6 104.2 36.0 9539.7 87.3 84.3 8948.0 100.1 60.3 9108.6 103.5 34.7 10107.9
26.7 95.9 89.6 8739.5 104.0 77.5 9077.7 106.6 55.9 9739.8 89.3 86.2 9133.1 103.8 79.6 9333.7 105.9 52.0 10358.0
29.4 98.1 91.6 9004.6 106.3 94.1 9328.5 108.9 64.8 10089.9 91.3 88.2 9398.2 104.5 97.3 9534.5 108.2 67.7 10669.0
32.2 100.2 93.6 9304.7 108.6 106 9678.6 111.3 78.6 10490.0 93.4 90.2 9698.3 107.7 104 9884.6 110.5 84.0 11069.1
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
