Rooftop ClimaCreator series DM16-01.01.27en
Service manual 57
MRCT-100CWN1-R(C)
Cooling capacity: (Continued)
Gross Cooling Capacity
Ambient DB(°C) 48 51.7
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
3,300
23.9 77.8 76.1 10815.0 93.2 55.4 12301.3 110.7 33.7 13675.5 72.2 70.6 11720.9 85.8 51.4 13095.1 102.1 32.1 14322.6
26.7 79.7 78.0 11126.5 95.4 75.3 12481.2 113.3 53.0 14025.7 73.9 72.3 12032.5 87.8 69.5 13231.9 104.4 49.6 14664.2
29.4 81.6 79.8 11622.5 97.6 94.3 13003.1 115.8 71.9 14573.4 75.6 74.0 12519.1 89.8 86.8 13744.3 106.7 66.8 15202.5
32.2 83.4 81.6 12136.9 99.7 96.3 13535.3 118.3 90.5 15123.4 77.3 75.6 13042.1 91.7 88.7 14320.5 109.0 83.7 15752.5
4,100
23.9 80.8 79.1 11073.8 96.2 58.4 12560.2 113.7 36.7 13934.3 75.2 73.6 11979.8 88.8 54.4 13354.0 105.1 35.1 14581.5
26.7 82.7 81.0 11385.4 98.4 78.3 12705.0 116.3 56.0 14284.5 76.9 75.3 12291.4 90.8 72.5 13490.7 107.4 52.6 14923.0
29.4 84.6 82.8 11881.4 100.6 97.3 13261.9 118.8 74.9 14832.3 78.6 77.0 12778.0 92.8 89.8 14003.2 109.7 69.8 15461.4
32.2 86.4 84.6 12395.7 102.7 99.3 13794.1 121.3 93.5 15382.3 80.3 78.6 13301.0 94.7 91.7 14579.3 112.0 86.7 16011.4
4,600
23.9 83.7 80.7 11324.0 98.1 62.2 12724.1 114.6 37.4 14012.0 77.8 75.1 12204.1 90.5 57.9 13500.7 105.9 35.7 14650.5
26.7 85.7 82.6 11644.2 102.1 83.3 13059.3 117.2 58.8 14362.2 76.8 84.8 12524.3 94.8 77.1 13835.9 108.3 55.2 15000.7
29.4 87.6 84.5 12140.2 102.6 97.7 13433.7 119.8 79.1 14918.6 78.5 86.7 13019.5 95.2 92.7 14210.3 110.6 73.6 15539.1
32.2 89.5 86.3 12663.2 104.7 103 13966.7 122.3 98.9 15468.6 80.2 88.5 13542.5 96.6 94.6 14743.3 112.9 91.6 16089.1
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
