Rooftop ClimaCreator series DM16-01.01.27en
Service manual 59
MRCT-125CWN1-R(C)
Cooling capacity: (Continued)
Gross Cooling Capacity
Ambient DB(°C) 40.6 46.1
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
3,500
23.9 111.1 104 12036.3 130.1 78.8 13848.3 146.3 50.9 15387.9 100.6 98.5 13610.7 118.6 73.2 15331.9 140.0 47.6 17382.1
26.7 113.4 106 12344.9 132.7 101 14171.9 149.3 73.5 15737.9 102.6 101 13919.3 121.0 96.8 15655.5 142.9 70.6 17732.1
29.4 115.8 108 12784.2 135.6 125 14656.6 152.4 95.0 16245.3 104.9 103 14358.6 123.6 120 16128.9 145.9 93.2 18239.5
32.2 118.2 111 13295.9 138.3 137 15178.2 155.5 116 16795.3 107.0 105 14870.3 126.1 122 16650.5 148.9 116 18789.5
5,500
23.9 115.1 112 12410.7 133.2 83.3 14143.3 147.2 51.9 15478.7 104.0 100 13939.7 120.8 77.8 15547.5 141.1 48.5 17484.3
26.7 117.5 114 12730.7 135.9 108 14478.3 150.2 76.4 15828.7 106.2 103 14259.7 125.4 103 16075.4 144.0 73.9 17834.3
29.4 120.0 117 13181.4 138.8 134 14963.0 153.3 100 16336.1 108.5 105 14699.0 126.0 124 16335.8 147.1 98.3 18353.0
32.2 122.4 119 13693.0 141.6 139 15484.6 156.4 122 16886.1 110.7 107 15222.0 128.5 126 16877.5 150.1 122 18903.0
6,400
23.9 117.5 110 12637.7 135.2 86.7 14336.2 147.9 52.5 15546.8 107.8 105 14291.5 123.7 82.0 15819.8 142.0 49.4 17563.7
26.7 119.9 112 12957.7 138.0 116 14671.2 150.9 78.7 15896.8 109.9 107 14611.5 126.2 110 16154.8 144.8 77.2 17913.7
29.4 122.4 114 13408.3 140.9 136 15155.9 154.2 102 16415.5 112.3 110 15062.2 129.0 126 16639.5 147.9 103 18432.4
32.2 124.9 117 13931.3 143.7 139 15688.9 157.3 126 16965.5 114.6 112 15585.2 131.6 130 17172.5 150.9 128 18982.4
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
