Midea MRCT-200CWN1-R(C)

DM16‐01.01.27en  RooftopClimaCreatorseries
82 Service manual
MRCT-100CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5
0
Fan speed (rpm)
/ / / / / / 962 946 931
Power input (W)
/ / / / / / 2,020 1,945 1,870
Air flow (CFM)
/ / / / / / 4,571 4,500 4,428
25
Fan speed (rpm)
/ / / / / 969 964 969 933
Power input (W)
/ / / / / 2,010 1,930 1,855 1,780
Air flow (CFM)
/ / / / / 4,442 4,398 4,323 4,248
50
Fan speed (rpm)
/ / / / 977 972 967
972 935
Power input (W)
/ / / / 1,990 1,915 1,840
1,765 1,690
Air flow (CFM)
/ / / / 4,320 4,272 4,224
4,146 4,067
75
Fan speed (rpm)
/ / / 981 980 975 970 975 937
Power input (W)
/ / /
1,998 1,915 1,843 1,770 1,695 1,620
Air flow (CFM)
/ / /
4,214 4,183 4,127 4,072 3,997 3,922
100
Fan speed (rpm)
/ /
986
984 982 977 972 977 938
Power input (W)
/ /
2,000
1,900 1,800 1,730 1,660 1,590 1,520
Air flow (CFM)
/ /
4,129
4,052 3,974 3,905 3,835 3,771 3,707
125
Fan speed (rpm)
/ 989 989 987 985 980 975 980 940
Power input (W)
/ 1,980 1,960 1,833 1,705 1,635 1,565 1,495 1,425
Air flow (CFM)
/ 3,953 4,065 3,927 3,789 3,719 3,648 3,579 3,509
150
Fan speed (rpm)
1,009 991 991 990 988 983 978 983 942
Power input (W)
2,050 1,880 1,865 1,738 1,610 1,540 1,470 1,400 1,330
Air flow (CFM)
3,830 3,778 3,891 3,748 3,605 3,532 3,460 3,386 3,312
175
Fan speed (rpm)
1,011 933 994 992 990 / / / /
Power input (W)
1,945 1,775 1,770 1,638 1,505 / / / /
Air flow (CFM)
3,656 3,586 3,718 3,549 3,381 / / / /
200
Fan speed (rpm)
1,012 995 997 995 993 / / / /
Power input (W)
1,840 1,670 1,660 1,530 1,400 / / / /
Air flow (CFM)
3,481 3,394 3,517 3,337 3,157 / / / /
225
Fan speed (rpm)
1,014 996 1,000 / / / / / /
Power input (W)
1,725 1,545 1,550 / / / / / /
Air flow (CFM)
3,292 3,148 3,316 / / / / / /
250
Fan speed (rpm)
1,016 998 1,002 / / / / / /
Power input (W)
1,610 1,420 1,425 / / / / / /
Air flow (CFM)
3,104 2,902 3,048 / / / / / /
Notes:
1. Legend: X – Regulation space of motor pulley (mm); N: Number of turns; ESP: External static pressure (in.w.g);
2: Pulley pitch factory set point: The table, No. of turns (N) = 5;
3. Bold data is the performance testing set point;
4. Shading data are rated airflow.
