Maintenance and
Disassembly
Page 59
Procedure Illustration
5) Disconnect the connector for fan motor
from the electronic control board (see
CJ_ODU_INV_004).
6) Remove the fixing screws of the fan motor
(4 screws) (see CJ_ODU_INV_005).
7) Remove the fan motor.
CJ_ODU_INV_004
CJ_ODU_INV_005
Note: This section is for reference only. Actual unit appearance may vary.
Fan Motor
