DM13-01.01.16en Air-cooled Package
Service manual 9
Model MTA-120CRN1 MTA-120HRN1 MTA-150CRN1 MTA-150CRN1
Power supply -
220~240V-1Ph-50Hz
220~240V-1Ph-50Hz
Temp. setting range ℃ ≥17 ≤30 ≥17 ≤30
Rated input power W 17300 17300 21200 21200
Rated current A 28.6 28.6 35 35
Cooling
Capacity
Btu/h
120000 120000
150000 150000
W
35000 35000 44000 44000
Input W 12000 12000 15100 15100
EER W/W 2.92 2.92 2.91 2.91
Heating
Capacity
Btu/h
/ 120000
/ 160000
W
/ 38000
/ 47000
Input W / 12600 / 15700
COP W/W / 3.02 / 3
Indoor air flow m
3
/h
6375 6375
7650 7650
Indoor standard ESP Pa
150 150
150 150
Indoor noise level dB(A)
56 56
56 56
Refrigerant
Type - R410A R410A R410A R410A
Control - Capillary Capillary
Fan
Type - Centrifugal fan Centrifugal fan Centrifugal fan Centrifugal fan
Dimension mm Φ307 Φ307 Φ307 Φ307
Drive type/ Motor step - Direct/ Single Direct/ Single Direct/ Single Direct/ Single
Motor input * No. W
498*3 498*3
630*3 630*3
Motor speed rpm
860 860
1202 1202
Coil
Type - Copper tube and aluminum fin Copper tube and aluminum fin
Tube size mm Φ7 Φ7 Φ7 Φ7
No. of rows 4 4 4 4
Fin per inch FPI 17 17 17 17
Length* height mm
1602*588 1602*588
1602*588 1602*588
Controller - Remote controller Remote controller
Drain pipe size mm 41 41 41 41
Dimension (W*H*D) mm
1828*858*638 1828*858*638
1828*858*638 1828*858*638
Packing (W*H*D) mm
2095*929*689 2095*929*689
2095*929*689 2095*929*689
Net/Gross weight kg
188/220 188/220
188/200 188/200
Shipping Qty per (20'/40'/40'HD) pcs
19/42/46 19/42/46 19/42/46 19/42/46
Notes:
1. ESP: external static pressure
2. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°CWB; Equivalent refrigerant piping: 7.5m (horizontal).
3. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°CWB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m (horizontal).
