DM13-01.01.16en Air-cooled Package
Service manual 35
9. Electric Characteristics
Model
Indoor Unit Power Supply IFM
Hz Voltage Min. Max. MCA MFA kW FLA
MTA-76CRN1 50 220-240 198 254 7.53 15 1.341 6.02
MTA-76HRN1 50 220-240 198 254 7.53 15 1.341 6.02
MTA-96CRN1 50 220-240 198 254 9.1 15 1.605 7.28
MTA-96HRN1 50 220-240 198 254 9.1 15 1.605 7.28
MTA-120CRN1 50 220-240 198 254 11.19 20 2.03 8.95
MTA-120HRN1 50 220-240 198 254 11.19 20 2.03 8.95
MTA-150CRN1 50 220-240 198 254 16.5 15 2.7 13.2
MTA-150HRN1 50 220-240 198 254 16.5 15 2.7 13.2
MHB-76CRN1 50 220-240 198 254 9.51 15 1.652 7.61
MHB-76HRN1 50 220-240 198 254 9.51 15 1.652 7.61
MHB-96CRN1 50 220-240 198 254 11.21 - 2.005 8.97
MHB-96HRN1 50 220-240 198 254 11.21 - 2.005 8.97
Note:
MCA: Min. Current Amps. (A)
MFA: Max. Fuse Amps. (A)
IFM: Indoor Fan Motor
kW: Fan Motor Rated Output (kW)
FLA: Full Load Amps. (A)
Model
Outdoor Unit Power Supply Compressor OFM
Hz Voltage Min. Max. MCA TOCA MFA MSC RLA KW FLA
MOV-76CN1-C 50 380-415 342 438 17.5 18 27 48*2 6.3*2 0.573 2.613
MOV-76HN1-C 50 380-415 342 438 17.5 18 27 48*2 6.3*2 0.573 2.613
MOV-96CN1-C 50 380-415 342 438 20 21 31.5 53*2 8*2 1.373 6.26
MOV-96HN1-C 50 380-415 342 438 20 21 31.5 53*2 8*2 1.373 6.26
MOV-120CN1-C 50 380-400 342 440 25 28.6 30 147 21.4 1.373 6.26
MOV-120HN1-C 50 380-400 342 440 25 28.6 30 147 21.4 1.373 6.26
Note:
MCA: Min. Current Amps. (A) TOCA: Total Over-current Amps. (A)
MFA: Max. Fuse Amps. (A) MSC: Max. Starting Amps. (A)
RLA: Rated Locked Amps. (A) OFM: Outdoor Fan Motor
KW: Rated Motor Output (KW) FLA: Full Load Amps. (A)
