Midea MTA-76CRN1 Service Manual

Air-cooled Package DM13-01.01.16en
52 Service manual
5. Electric Characteristics
Model
Outdoor Unit Power Supply Compressor OFM
Hz Voltage Min. Max. MCA TOCA MFA MSC RLA KW FLA
MOV-76C-C 50 380-415V 342V 438V 17.5 18 27 48*2 6.3*2 0.573 2.613
MOV-76H-C 50 380-415V 342V 438V 17.5 18 27 48*2 6.3*2 0.573 2.613
MOV-96C-C 50 380-415V 342V 438V 20 21 31.5 53*2 8*2
1.373 6.26
MOV-96H-C 50 380-415V 342V 438V 20 21 31.5 53*2 8*2
1.373 6.26
MOV-120C-C 50 380-400V 342V 440V 25 28.6 30 147 21.4 1.373 6.26
MOV-120H-C 50 380-400V 342V 440V 25 28.6 30 147 21.4 1.373 6.26
Remark:
MCA: Min. Current Amps. (A)
TOCA: Total Over-current Amps. (A)
MFA: Max. Fuse Amps. (A)
MSC: Max. Starting Amps. (A)
RLA: Rated Locked Amps. (A)
OFM: Outdoor Fan Motor.
FLA: Full Load Amps. (A)
KW: Rated Motor Output (kW)
