DM13-01.01.16en Air-cooled Package
Service manual 21
7.1.2 MTA-76HRN1
Gross Cooling Capacity (kW)
Outdoor DB(°C) 29.40 35.00
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
2000
23.9 19.2 15.0 6.38 21.6 12.2 6.58 23.0 5.3 6.71 18.4 15.1 6.81 20.5 11.6 7.04 21.7 5.0 7.18
26.7 19.9 17.2 6.40 22.1 14.3 6.60 23.5 10.1 6.73 18.8 17.1 6.83 20.9 13.5 7.06 22.2 9.6 7.20
29.4 20.6 18.7 6.42 22.5 18.5 6.62 23.9 14.3 6.75 19.2 18.4 6.85 21.3 17.5 7.08 22.6 13.5 7.22
32.2 21.3 20.9 6.43 23.0 20.9 6.63 24.4 18.0 6.76 19.6 19.2 6.86 21.7 19.7 7.10 23.1 17.0 7.24
2300
23.9 20.3 16.2 6.58 22.3 12.9 6.78 23.6 5.6 6.91 19.4 16.3 7.01 21.1 12.2 7.24 22.4 5.3 7.38
26.7 21.0 18.3 6.60 22.7 16.1 6.80 24.1 10.6 6.93 19.8 18.3 7.03 21.5 15.2 7.26 22.8 10.0 7.40
29.4 21.7 20.1 6.62 23.2 19.5 6.82 24.6 15.0 6.95 20.2 19.8 7.05 21.9 18.4 7.28 23.3 14.2 7.42
32.2 22.5 21.4 6.63 23.6 21.9 6.83 25.1 18.7 6.96 20.6 20.6 7.07 22.4 20.7 7.30 23.7 17.7 7.44
2500
23.9 20.8 18.1 6.82 22.7 14.2 7.15 24.1 6.2 7.15 19.9 18.3 7.25 21.6 13.5 7.48 22.8 5.9 7.62
26.7 21.5 20.5 6.84 23.2 17.8 7.04 24.6 11.8 7.17 20.3 20.3 7.27 22.0 16.9 7.50 23.3 11.1 7.64
29.4 22.3 21.6 6.86 23.7 21.7 7.06 25.1 16.6 7.19 20.7 20.7 7.29 22.4 20.6 7.52 23.8 15.7 7.66
32.2 23.0 22.6 6.87 24.1 21.9 7.08 25.6 20.8 7.21 21.1 21.1 7.31 22.9 20.8 7.54 24.2 19.7 7.68
2800
23.9 21.3 18.8 7.13 23.2 13.9 7.33 24.6 6.0 7.46 20.7 18.3 7.56 22.1 13.2 7.79 23.3 5.7 7.93
26.7 22.0 21.2 7.15 23.7 17.4 7.35 25.1 11.4 7.48 21.1 20.3 7.58 22.5 16.5 7.81 23.8 10.8 7.95
29.4 22.8 22.1 7.17 24.2 21.0 7.37 25.6 16.2 7.50 21.5 21.5 7.60 23.0 20.0 7.83 24.3 15.4 7.97
32.2 23.6 23.1 7.19 24.7 23.7 7.39 26.1 20.2 7.52 22.0 22.0 7.62 23.4 22.5 7.85 24.8 19.2 7.99
