DM13-01.01.16en Air-cooled Package
Service manual 31
7.1.7 MTA-150CRN1
Gross Cooling Capacity (kW)
Outdoor DB(°C) 29.40 35.00
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
4000
23.9 41.0 32.0 14.20 43.7 24.7 14.40 45.1 10.4 14.53 40.5 33.2 14.63 42.5 24.0 14.86 43.8 10.1 15.00
26.7 42.4 36.6 14.24 44.6 28.9 14.44 46.0 19.8 14.57 41.3 37.5 14.67 43.4 28.1 14.90 44.7 19.3 15.04
29.4 43.9 39.9 14.28 45.5 37.3 14.48 46.9 27.9 14.61 42.1 40.5 14.71 44.2 36.3 14.94 45.6 27.1 15.08
32.2 45.4 44.5 14.31 46.4 42.2 14.51 47.8 35.2 14.64 43.0 42.1 14.74 45.1 41.0 14.97 46.5 34.2 15.12
4300
23.9 42.0 33.6 14.40 44.3 25.6 14.60 45.7 10.8 14.73 41.5 34.8 14.83 43.1 24.9 14.99 44.4 10.5 15.20
26.7 43.5 37.8 14.44 45.2 32.1 14.64 46.6 20.4 14.77 42.3 39.2 14.87 44.0 31.2 15.01 45.3 19.9 15.24
29.4 45.0 41.7 14.48 46.1 38.7 14.68 47.5 29.0 14.81 43.1 42.3 14.91 44.9 37.7 15.03 46.2 28.2 15.28
32.2 46.6 44.4 14.51 47.0 43.5 14.71 48.5 36.2 14.84 44.0 44.0 14.94 45.8 42.4 15.05 47.1 35.2 15.32
4500
23.9 42.5 37.0 14.64 44.8 28.0 14.97 46.2 12.0 14.97 42.0 38.5 15.07 43.6 27.3 15.08 44.9 11.6 15.44
26.7 44.0 41.9 14.68 45.7 35.2 14.88 47.1 22.5 15.01 42.8 42.8 15.11 44.0 34.2 15.10 45.8 21.9 15.48
29.4 45.5 44.2 14.72 46.6 42.8 14.92 48.0 31.8 15.05 43.7 43.7 15.15 45.4 41.6 15.38 46.7 30.9 15.52
32.2 47.1 46.2 14.75 47.5 43.2 14.95 49.0 39.8 15.09 44.5 44.5 15.19 46.3 42.1 15.42 47.7 38.7 15.56
4800
23.9 43.0 38.0 14.95 45.3 27.1 15.15 46.7 11.4 15.28 42.7 37.8 15.38 44.1 26.4 15.61 45.4 11.1 15.75
26.7 44.5 42.8 14.99 46.2 34.0 15.19 47.6 21.6 15.32 43.6 41.9 15.42 45.0 33.1 15.65 46.3 21.0 15.79
29.4 46.1 44.7 15.03 47.1 41.0 15.23 48.6 30.7 15.36 44.5 44.5 15.46 45.9 39.9 15.69 47.2 29.9 15.83
32.2 47.7 46.7 15.07 48.1 46.2 15.27 49.5 38.4 15.40 45.4 45.4 15.50 46.8 45.0 15.73 48.2 37.3 15.87
