DM13-01.01.16en Air-cooled Package
Service manual 49
Foundation of the outdoor unit
7
5
7
m
m
6
7
1
m
m
1
0
H
P
15×20 rectangular hole
≥500 mm
≥500 mm
M12 foundation bol
t
4 screws for 1 unit
