Midea MTA-76CRN1 Service Manual

DM13-01.01.16en Air-cooled Package
Service manual 87
Outdoor unit:
Model MOV-76CN1-C MOV-76HN1-C MOV-96CN1-C MOV-96HN1-C
Power supply
380~415V-
3N-50Hz
380~415V-
3N-50Hz
380~415V-
3N-50Hz
380~415V-
3N-50Hz
Capacity of power
supply/ fuse (A)
60/40 60/40 60/40 60/40
Powe
r
supply
cable
YCW-450/750
4*6.0 mm
2
YCW-450/750
4*6.0 mm
2
YCW-450/750
4*6.0 mm
2
YCW-450/750
4*6.0 mm
2
Grounded wire
YCW-450/750
6.0 mm
2
YCW-450/750
6.0 mm
2
YCW-450/750
6.0 mm
2
YCW-450/750
6.0 mm
2
Connective wire of
indoor to outdoor
unit
RVV-300/500
2*1.0 mm
2
RVV-300/500
4*1.0 mm
2
RVV-300/500
2*1.0 mm
2
RVV-300/500
4*1.0 mm
2
Wire controls
connective wire
RVVP-300/300
5*0.5mm²
RVVP-300/300
5*0.5mm²
RVVP-300/300
5*0.5mm²
RVVP-300/300
5*0.5mm²
Model MOV-120CN1-C MOV-120HN1-C
Power supply
380~415V-
3N-50Hz
380~415V-
3N-50Hz
Capacity of power
supply/ fuse (A)
60/40 60/40
Powe
r
supply
cable
YCW-450/750
4*6.0 mm
2
YCW-450/750
4*6.0 mm
2
Grounded wire
YCW-450/750
6.0 mm
2
YCW-450/750
6.0 mm
2
Connective wire of
indoor to outdoor
unit
RVV-300/500
2*1.0 mm
2
RVV-300/500
4*1.0 mm
2
Wire controls
connective wire
RVVP-300/300
5*0.5mm²
RVVP-300/300
5*0.5mm²
