Specifications
Page 74
Model
Outdoor Unit Power Supply Compressor OFM
Phase Hz Voltage MCA MFA MSC RLA Qty kW FLA
M2OG-14HFN8-Q
1 50 220-240
11.5 20 - 7.5 1 0.034 0.39
M2OC-18HFN8-Q 12 20 - 7.1 1 0.040 0.7
M2OD-18HFN8-Q 13 20 - 7.5 1 0.058 0.39
M3OF-21HFN8-Q 15.5 20 - 7.5 1 0.050 0.55
M3OE-27HFN8-Q 15 30 - 9.4 1 0.050 0.55
M3OF-27HFN8-Q 17.5 22 - 9.45 1 0.050 0.55
M4OE-28HFN8-Q 19 30 - 9.45 1 0.120 1.21
M4OB-36HFN8-Q 21.5 30 - 5.38 1 0.120 1.39
M5OD-42HFN8-Q 22 30 - 5.38 1 0.120 1.39
Notes:
MCA: Minimum Circuit Amperes (A)
MFA: Maximum Fuse Amperes (A)
MSC: Maximum Starting Current
RLA: Rated Load Amperes (A)
IFM: Indoor Fan Motor
OFM: Outdoor Fan Motor
FLA: Full Load Amperes (A)
