Part 2
-
Outdoor Unit Engineering Data
8.2 Heating Capacity Tables
Table2-8.4:120 model heating capacity
CR
Outdoor
air temp.
Indoor air temp. °C DB
16.0
18.0
20.0
21.0
22.0
24.0
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
°C DB
°C WB
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
130%
-19.8
-20.0
10.2
4.5
10.1
4.5
10.1
4.6
10.1
4.6
10.0
4.6
10.0
4.7
-18.8
-19.0
10.6
4.5
10.5
4.5
10.4
4.6
10.4
4.6
10.4
4.7
10.3
4.8
-16.7
-17.0
11.2
4.5
11.1
4.6
11.1
4.7
11.0
4.7
11.0
4.8
11.0
4.9
-13.7
-15.0
11.9
4.6
11.8
4.7
11.7
4.7
11.7
4.8
11.7
4.8
11.6
5.0
-11.8
-13.0
12.6
4.7
12.5
4.7
12.4
4.8
12.4
4.9
12.3
5.0
12.3
5.1
-9.8
-11.0
13.3
4.7
13.2
4.8
13.1
4.9
13.1
5.0
13.0
5.1
13.0
5.2
-9.5
-10.0
13.7
4.8
13.6
4.9
13.5
5.0
13.4
5.1
13.4
5.1
13.3
5.3
-8.5
-9.1
14.0
4.8
13.9
4.9
13.8
5.1
13.7
5.1
13.7
5.2
13.6
5.3
-7.0
-7.6
14.5
4.9
14.4
5.0
14.3
5.1
14.3
5.2
14.2
5.3
14.2
5.4
-5.0
-5.6
15.3
5.0
15.2
5.1
15.0
5.3
15.0
5.4
15.0
5.4
14.9
5.6
-3.0
-3.7
16.0
5.1
15.9
5.3
15.8
5.4
15.7
5.5
15.7
5.6
15.4
5.6
0.0
-0.7
17.2
5.3
17.0
5.5
16.9
5.6
16.9
5.7
16.8
5.7
15.4
5.2
3.0
2.2
18.3
5.5
18.2
5.7
18.2
5.9
17.5
5.6
16.8
5.3
15.4
4.8
5.0
4.1
19.1
5.7
18.8
5.7
18.2
5.6
17.5
5.3
16.8
5.1
15.4
4.6
7.0
6.0
19.7
5.7
19.6
5.8
18.2
5.3
17.5
5.1
16.8
4.8
15.4
4.3
9.0
7.9
20.3
5.7
19.6
5.5
18.2
5.1
17.5
4.8
16.8
4.6
15.4
4.1
11.0
9.8
21.0
5.8
19.6
5.3
18.2
4.8
17.5
4.6
16.8
4.3
15.4
3.9
13.0
11.8
21.0
5.4
19.6
5.0
18.2
4.5
17.5
4.3
16.8
4.1
15.4
3.7
15.0
13.7
21.0
5.2
19.6
4.7
18.2
4.3
17.5
4.0
16.8
3.8
15.4
3.5
120%
-19.8
-20.0
10.2
4.5
10.1
4.5
10.0
4.6
10.0
4.6
10.0
4.7
10.0
4.8
-18.8
-19.0
10.5
4.5
10.4
4.6
10.4
4.6
10.3
4.7
10.3
4.7
10.3
4.8
-16.7
-17.0
11.1
4.6
11.1
4.6
11.0
4.7
11.0
4.8
11.0
4.8
10.9
4.9
-13.7
-15.0
11.8
4.6
11.7
4.7
11.7
4.8
11.6
4.9
11.6
4.9
11.6
5.0
-11.8
-13.0
12.5
4.7
12.4
4.8
12.3
4.9
12.3
5.0
12.3
5.0
12.2
5.2
-9.8
-11.0
13.2
4.8
13.1
4.9
13.0
5.0
13.0
5.1
12.9
5.1
12.9
5.3
-9.5
-10.0
13.5
4.8
13.4
5.0
13.4
5.1
13.3
5.1
13.3
5.2
13.2
5.4
-8.5
-9.1
13.9
4.9
13.8
5.0
13.7
5.1
13.6
5.2
13.6
5.3
13.5
5.4
-7.0
-7.6
14.4
5.0
14.3
5.1
14.2
5.2
14.2
5.3
14.1
5.4
14.2
5.6
-5.0
-5.6
15.1
5.1
15.0
5.2
14.9
5.4
14.9
5.5
14.8
5.5
14.2
5.3
-3.0
-3.7
15.9
5.2
15.7
5.4
15.6
5.5
15.6
5.6
15.5
5.6
14.2
5.1
0.0
-0.7
17.0
5.4
16.9
5.6
16.8
5.7
16.2
5.5
15.5
5.2
14.2
4.7
3.0
2.2
18.2
5.7
18.1
5.8
16.8
5.3
16.2
5.1
15.5
4.8
14.2
4.4
5.0
4.1
18.8
5.7
18.1
5.5
16.8
5.0
16.2
4.8
15.5
4.6
14.2
4.1
7.0
6.0
19.4
5.7
18.1
5.2
16.8
4.8
16.2
4.6
15.5
4.4
14.2
3.9
9.0
7.9
19.4
5.4
18.1
5.0
16.8
4.5
16.2
4.3
15.5
4.1
14.2
3.7
11.0
9.8
19.4
5.1
18.1
4.7
16.8
4.3
16.2
4.1
15.5
3.9
14.2
3.5
13.0
11.8
19.4
4.8
18.1
4.4
16.8
4.0
16.2
3.8
15.5
3.7
14.2
3.3
15.0
13.7
19.4
4.6
18.1
4.2
16.8
3.8
16.2
3.6
15.5
3.4
14.2
3.1
110%
-19.8
-20.0
10.1
4.5
10.0
4.6
10.0
4.6
10.0
4.7
10.0
4.7
10.0
4.8
-18.8
-19.0
10.4
4.5
10.3
4.6
10.3
4.7
10.3
4.7
10.3
4.8
10.3
4.9
-16.7
-17.0
11.0
4.6
11.0
4.7
10.9
4.8
10.9
4.8
10.9
4.9
10.9
5.0
-13.7
-15.0
11.7
4.7
11.6
4.8
11.6
4.9
11.6
4.9
11.5
5.0
11.5
5.1
-11.8
-13.0
12.4
4.8
12.3
4.9
12.2
5.0
12.2
5.0
12.2
5.1
12.2
5.3
-9.8
-11.0
13.1
4.9
13.0
5.0
12.9
5.1
12.9
5.2
12.9
5.2
13.0
5.5
-9.5
-10.0
13.4
4.9
13.3
5.0
13.3
5.2
13.2
5.2
13.2
5.3
13.0
5.4
-8.5
-9.1
13.7
5.0
13.6
5.1
13.6
5.2
13.5
5.3
13.5
5.4
13.0
5.2
-7.0
-7.6
14.3
5.1
14.2
5.2
14.1
5.3
14.1
5.4
14.2
5.6
13.0
5.1
-5.0
-5.6
15.0
5.2
14.9
5.3
14.8
5.5
14.8
5.5
14.2
5.3
13.0
4.8
-3.0
-3.7
15.7
5.3
15.6
5.5
15.4
5.5
14.8
5.3
14.2
5.1
13.0
4.6
0.0
-0.7
16.9
5.6
16.6
5.6
15.4
5.1
14.8
4.9
14.2
4.7
13.0
4.3
3.0
2.2
17.8
5.6
16.6
5.2
15.4
4.7
14.8
4.5
14.2
4.3
13.0
3.9
5.0
4.1
17.8
5.3
16.6
4.9
15.4
4.5
14.8
4.3
14.2
4.1
13.0
3.7
7.0
6.0
17.8
5.1
16.6
4.7
15.4
4.3
14.8
4.1
14.2
3.9
13.0
3.5
9.0
7.9
17.8
4.8
16.6
4.4
15.4
4.0
14.8
3.9
14.2
3.7
13.0
3.4
11.0
9.8
17.8
4.5
16.6
4.2
15.4
3.8
14.8
3.6
14.2
3.5
13.0
3.2
13.0
11.8
17.8
4.3
16.6
3.9
15.4
3.6
14.8
3.4
14.2
3.3
13.0
3.0
15.0
13.7
17.8
4.0
16.6
3.7
15.4
3.4
14.8
3.2
14.2
3.1
13.0
2.8
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
