Page 7
Unit
Specifications
and Features
1
Unit Specifications
MODEL
MWB06CW71 MWB08CW71 MWB10CW71
Power supply Ph-V-Hz
1Ph, 115V-, 60Hz 1Ph-115V-60Hz 1Ph-115V-60Hz
Cooling
Rated Capacity Btu/h
6000 8000 10000
Rated EER Btu/w.h,w/w
12,2 12,0 12,0
Rated CEER Btu/w.h,w/w
12,1 12,0 12,0
Rated input W
490 666 833
Rated current A
4.5 5.9 7.5
Standby power W
0.9 0.9 1.0
Moisture Removal L/h
0,7 1 1,1
Max. input consuption W
700 830 992
Max. current A
6,5 8 9,79
Starting current A
21.0 29 35
Outdoor noise level (Hi/Med/Lo) dB(A)
63.2/60.8/58.1 64.5/62.6/59.2 66.7/64.6/61.7
Plug type (NEMA#)
5-15P 5-15P 5-15P
Power cord length
mm
1980 1980 1980
ft
6.5 6.5 6.5
Control type
Remote Control Remote Control Remote Control
Operating
temperature
Indoor
(cooling/heating)
°C
17-32/--- 17-32/--- 17-32/---
°F
62-90 62-90 62-90
Outdoor
(cooling/heating)
°C
18-43/--- 18-43/--- 18-43/---
°F
64-109 64-109 64-109
Application area
(Cooling Standard)
m
2
8-12 11-16 13-20
sq.ft
86-129 118-172 140-215
Application area (Cooling EPA) sp.ft
150-250 300-350 400-450
Dimension (W*D*H)
mm
471*450*340 471*494*340 482x595x372
in
18.5*17.7*13.4 18.5*19.5*13.4 19x23.5x14.6
Packing (W*D*H)
mm
561*502*370 561*545*370 557x636x430
in
22.09*19.8*14.6 22.09*21.49*14.6 21.9x24.1x16.9
Net/Gross weight
kg
20.5/23.6 22.2/25.3 27.7/31.2
lb
45.1/52.0 48.8/55.7 61.1/68.8
Loading quantity 40’HQ Pieces
668 576 424
Window
Opening
Width (Min/Max) in
23/36 23/36 23/36
Height (Min/Max) in
14 14 15,5
