(Fig.2)
Water flow
adjusting
valve with
filter
Cold water inlet
Cold water inlet
3.4 Plumbing Connection
⑤
Mount the unit on the wall and tighten with two screws at bottom, connect the wires and
install top cover with the screws.
①
②
Shower flexible tube should be connected with water outlets and shower head separately,
attached sealing ring should be used at end face.
Water valve with filter should be installed at water inlet of the unit, sealing ring with filter
should be used at end face. (See Fig.2).
(Fig.1)
WARNING
Metallic / chromed hose and conductive control valve shall not be used.
!
