PART FIGURE
Caster assembly
Thermostat Knob
Power Switch Knob
Cord wrap
Fin
Use of oil filled radiator
butterfly nuts
control box
figure 1 figure 2
1,Turn the heater upside down.
2. As shown in figure 1, align the mounting hole of a set of caster assembly
and install it on the screw of the caster pad plate at the end of the radiator fin,
and The other caster assembly is aligned to the screws mounted at the
bottom of the control box.
3,As shown in figure 2, two sets of caster components are tightened with four
butterfly nuts. Install solid and then put the heater in place-just put the wheels
on the ground.
