Midea ODMFI-E-2110

173
 M5OG-48HFN1-M-[X], M4OI-36HFN1-M, M5OG-48HFN1-M (WE30 metal plate)
No
.
Part name
Procedures
Remarks
1
Fan
assembly
How to remove the fan
assembly.
1) Turn off the air
conditioner. Turn off the
power breaker.
2) Remove the screws of air
outlet grille(8 screws)
3) Remove the hex nut fixing
4) the fan.
5) Remove the fan.
6) Remove the screws of top
cover, and remove the top
cover. (4 screws)
③
Screws of top
cover
②
