Midea ODMFI-E-2110

174
7) Remove the screws of
front side panel, and
remove the front side
panel (1 screw)
8) Disconnect the fan motor
9) connectors
FAN1(3p,white) and
FAN2(3p,white) from DC
motor driver board.
10) Remove the fan motor
after unfastening fixing
screws.
2
Panel plate
How to remove the panel
plate.
6) Remove big handle.(2
screws) and water
collector(2 screws)
7) Remove 2 screws of
terminal board and 15
screws of right-rear panel,
and remove the right-rear
panel.
Screws of
Water collector
Screws
of big
handle
⑧
⑥
